| Onderdeel nommer | M240UW04 V0 |
| Handelsmerk | AUO |
| Grootte | 24.0 |
| Toepassing | DMPC |
| Resolusie | 1920×1200 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | M240UW04 V0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 24.0 inch |
| resolusie | 1920(RGB)×1200 , WUXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 518.4×324 mm |
| buitelyn | 546.4×352 mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC), CIE193172% |
| reaksie tyd | 3.4/1.6 (Typ.)(Tr/Td) |
| kykhoek | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 6 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (2 ch, 8-bit), 30 pins |
| insetspanning | 5.0V (Typ.) |
| aansoek | DMPC |
| G240HW01 V0 | AUO | 24.0 | 1920×1080 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| M240HVN01.0 | AUO | 24.0 | 1920×1080 |
| M240HW02 V6 | AUO | 24.0 | 1920×1080 |
| M240UP01 V0 | AUO | 24.0 | 1920×1200 |
| M240UW01 V0 | AUO | 24.0 | 1920×1200 |
| M240UW01 V2 | AUO | 24.0 | 1920×1200 |
| M240UW01 V3 | AUO | 24.0 | 1920×1200 |
| M240UW04 V0 | AUO | 24.0 | 1920×1200 |
| M240UW04 V1 | AUO | 24.0 | 1920×1200 |
| LM185TT2A | PANDA | 18.5 | 1366×768 |
| LM190WX2-TLK1 | LG Display | 19.0 | 1440×900 |
| LM270WQ1-SDDA | LG Display | 27.0 | 2560×1440 |
| LTM340YP02 | Samsung | 34 | 3440×1440 |
| M216H1-L01 | Innolux | 21.6 | 1920×1080 |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| MT215DW01 V.0 | Innolux | 21.5 | 1920×1080 |
| SVA190WX05TB | SVA-NEC | 19.0 | 1440×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
