| Onderdeel nommer | SVA190WX05TB |
| Handelsmerk | SVA-NEC |
| Grootte | 19.0 |
| Toepassing | DMPC |
| Resolusie | 1440×900 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | SVA-NEC |
| paneel model | SVA190WX05TB |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 19.0 inch |
| resolusie | 1440(RGB)×900 , WXGA+ |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 408.24×255.15 mm |
| buitelyn | 428×278 mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC), CIE193172% |
| reaksie tyd | |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 4 pcsCCFL |
| sein koppelvlak | LVDS (2 ch, 8-bit) |
| rohs: | |
| aansoek | DMPC |
