| Onderdeel nommer | LTY400HM10 |
| Handelsmerk | Samsung |
| Grootte | 40 |
| Toepassing | LCTV |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 470 |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | SAMSUNG |
| paneel model | LTY400HM10 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 40 inch |
| resolusie | 1920×1080(RGB) , FHD |
| vertoonmodus | S-PVA, Normally Black, Transmissive |
| aktiewe area | 885.6×498.15 mm |
| buitelyn | 915.7×528.8 mm |
| oppervlak | Antiglare (Haze 0.8%), Hard coating (2H) |
| helderheid | 470 cd/m² (Typ.) |
| kontras verhouding | 5000:1 (Typ.) |
| kleure vertoon | 1.07B (8-bit + Hi-FRC) |
| reaksie tyd | 8 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 2 stringsWLEDWithout Driver |
| sein koppelvlak | LVDS (2 ch, 10-bit), 51 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
| LTA400HL15 | Samsung | 40 | 1920×1080 |
| LTY400HA01 | Samsung | 40 | 1920×1080 |
| LTY400HC01 | Samsung | 40 | 1920×1080 |
| LTY400HC02 | Samsung | 40 | 1920×1080 |
| LTY400HF06 | Samsung | 40 | 1920×1080 |
| LTY400HL03 | Samsung | 40 | 1920×1080 |
| LTY400HM09 | Samsung | 40 | 1920×1080 |
| LTY400HM10 | Samsung | 40 | 1920×1080 |
| LTY400WS-L02 | Samsung | 40 | 1366×768 |
| T400HW01 V4 | AUO | 40 | 1920×1080 |
| LC260WUE-SBA1 | LG Display | 26.0 | 1920×1080 |
| LC320DXJ-SFA9 | LG Display | 31.5 | 1366×768 |
| LC320EXJ-SEE2 | LG Display | 31.5 | 1366×768 |
| LC420EUS-SCA1 | LG Display | 42 | 1920×1080 |
| LK315D3LA4S | SHARP | 31.5 | 1920×1080 |
| LTA460HT-L01 | Samsung | 46 | 1920×1080 |
| LTY400HM09 | Samsung | 40 | 1920×1080 |
| T420XW01 V5 | AUO | 42 | 1366×768 |
| T576DC01 V0 | AUO | 58 | 2560×1080 |
| V400DK1-KE1 | Innolux | 40 | 3840×2160 |
