| Onderdeel nommer | LTY400HA01 |
| Handelsmerk | Samsung |
| Grootte | 40 |
| Toepassing | LCTV |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 550 |
| CR | 1700:1 |
| Kleure | 1.07B |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | S-LCD |
| paneel model | LTY400HA01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 40 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | S-PVA, Normally Black, Transmissive |
| aktiewe area | 885.6×498.15 mm |
| buitelyn | 952×551×54.2 mm |
| oppervlak | Hard coating (3H) |
| helderheid | 550 cd/m² (Typ.) |
| kontras verhouding | 1700:1 (Typ.) |
| kleure vertoon | 1.07B (10-bit), CIE193190% |
| reaksie tyd | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 20 pcsCCFLEmbedded (Balance board) |
| sein koppelvlak | LVDS (2 ch, 10-bit), 51 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
| LTA400HH-L02 | Samsung | 40 | 1920×1080 |
| LTI400HA06 | Samsung | 40 | 1920×1080 |
| LTY400HA01 | Samsung | 40 | 1920×1080 |
| LTY400HC01 | Samsung | 40 | 1920×1080 |
| LTY400HC02 | Samsung | 40 | 1920×1080 |
| LTY400HF06 | Samsung | 40 | 1920×1080 |
| LTY400HL03 | Samsung | 40 | 1920×1080 |
| LTY400HM09 | Samsung | 40 | 1920×1080 |
| LTY400HM10 | Samsung | 40 | 1920×1080 |
| LTY400WS-L02 | Samsung | 40 | 1366×768 |
| LC320EUN-SFF1 | LG Display | 31.5 | 1920×1080 |
| LC370WUN-SBD1 | LG Display | 37 | 1920×1080 |
| LC420DUK-SGK2 | LG Display | 42 | 1920×1080 |
| LC420EUD-SDF1 | LG Display | 42 | 1920×1080 |
| LC550EQE-PHF1 | LG Display | 55 | 3840×2160 |
| LC550EUF-FGF1 | LG Display | 55 | 1920×1080 |
| LTA320HM01 | Samsung | 31.5 | 1920×1080 |
| T315HW02 V5 | AUO | 31.5 | 1920×1080 |
| T650HVF03.0 | AUO | 65 | 1920×1080 |
| V315B5-P10 | Innolux | 31.5 | 1366×768 |
