| Onderdeel nommer | G070Y3-T01 |
| Handelsmerk | Innolux |
| Grootte | 7.0 |
| Toepassing | IA |
| Resolusie | 800×480 |
| Samestelling | LCM |
| Helderheid | 600 |
| CR | 650:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | CMO |
| paneel model | G070Y3-T01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 7.0 inch |
| resolusie | 800(RGB)×480 , WVGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 156×82.8 mm |
| buitelyn | 168×94×6.65 mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 600 cd/m² (Typ.) |
| kontras verhouding | 650:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193160% |
| reaksie tyd | 5/11 (Typ.)(Tr/Td) |
| kykhoek | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 9S3PWLEDWithout Driver |
| sein koppelvlak | TTL (1 ch, 6-bit), 50 pins |
| insetspanning | 3.3/10.5/18/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aansoek | IA |
