| Onderdeel nommer | HE070IA-04R |
| Handelsmerk | Innolux |
| Grootte | 7.0 |
| Toepassing | PAD |
| Resolusie | 800×1280 |
| Samestelling | CELL |
| Helderheid | 0 |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | No B/L |
| Koppelvlak | LVDS |
| paneel handelsmerk | CHIMEI INNOLUX |
| paneel model | HE070IA-04R |
| paneel tipe | a-Si TFT-LCD , CELL |
| paneel grootte | 7.0 inch |
| resolusie | 800(RGB)×1280 , WXGA |
| vertoonmodus | IPS, Normally Black, Transmissive |
| aktiewe area | 94.2×150.72 mm |
| buitelyn | 101.5×159.52×1.27 mm |
| oppervlak | Hard coating |
| glas diepte | 0.50+0.50 mm |
| deurlaatbaarheid | 3.6% (Typ.)(with Polarizer) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193160% |
| reaksie tyd | 50 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| sein koppelvlak | LVDS (1 ch, 8-bit), 40 pins |
| insetspanning | 3.3/8.8/-7.0/22V (Typ.)(VDD/AVDD/VGH/VGL) |
| aansoek | PAD |
