| Onderdeel nommer | LTL070NL01-002 |
| Handelsmerk | Samsung |
| Grootte | 7.0 |
| Toepassing | PAD |
| Resolusie | 1024×600 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 800:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | SAMSUNG |
| paneel model | LTL070NL01-002 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 7.0 inch |
| resolusie | 1024(RGB)×600 , WSVGA |
| vertoonmodus | PLS, Normally Black, Transmissive |
| aktiewe area | 153.6×90 mm |
| buitelyn | 164.05×99.96×4.37 mm |
| oppervlak | Glare (Haze 0%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.2M (6-bit + FRC), CIE193150% |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 6S4PWLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (1 ch, 8-bit), 31 pins |
| insetspanning | 3.7V (Typ.) |
| aansoek | PAD |
