V400H1-L03

V400H1-L03
V400H1-L03
V400H1-L03 thumb V400H1-L03 thumb
Handelsmerk
Innolux
Grootte
40
Toepassing
LCTV
Resolusie
1920×1080
Samestelling
LCM
Helderheid
500
CR
4000:1
Kleure
16.7M
Agterlig
CCFL
Koppelvlak
LVDS
In Stock
2476
Spesifikasies

Onderdeel nommer V400H1-L03
HandelsmerkInnolux
Grootte40
ToepassingLCTV
Resolusie1920×1080
SamestellingLCM
Helderheid500
CR4000:1
Kleure16.7M
AgterligCCFL
KoppelvlakLVDS
paneel handelsmerkCMO
paneel modelV400H1-L03
paneel tipe a-Si TFT-LCD , LCM
paneel grootte40 inch
resolusie1920(RGB)×1080 , FHD
vertoonmodusMVA, Normally Black, Transmissive
aktiewe area885.6×498.15 mm
buitelyn952×551 mm
oppervlakAntiglare (Haze 17%), Hard coating (3H)
helderheid500 cd/m² (Typ.)
kontras verhouding4000:1 (Typ.)
kleure vertoon16.7M (8-bit), CIE193172%
reaksie tyd6.5 (Typ.)(G to G)
kykhoek88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekwensie60Hz
tipe lamp20 pcsCCFLEmbedded (Balance board)
sein koppelvlakLVDS (2 ch, 8-bit), 51 pins
insetspanning12.0V (Typ.)
aansoekLCTV
Familie Model
V400H1-L01 Innolux 40 1920×1080
V400H1-L03 Innolux 40 1920×1080
V400H1-L05 Innolux 40 1920×1080
V400H1-L10 Innolux 40 1920×1080
V400H1-L11 Innolux 40 1920×1080
V400H1-LHA Innolux 40 1920×1080
V400HJ6-ME2 Innolux 40 1920×1080
V400HJ6-PE1 Innolux 40 1920×1080
V400HK2-LS5 Innolux 40 1920×1080
V400HK7-PE6 Innolux 40 1920×1080
