| Onderdeel nommer | V400H1-LHA |
| Handelsmerk | Innolux |
| Grootte | 40 |
| Toepassing | LCTV |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 500 |
| CR | 6000:1 |
| Kleure | 1.07B |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | CHIMEI INNOLUX |
| paneel model | V400H1-LHA |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 40 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | Super MVA, Normally Black, Transmissive |
| aktiewe area | 885.6×498.15 mm |
| buitelyn | 952×551 mm |
| oppervlak | Antiglare (Haze 11%) |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 6000:1 (Typ.) |
| kleure vertoon | 1.07B (8-bit + Hi-FRC), CIE193172% |
| reaksie tyd | 5.5 (Typ.)(G to G) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekwensie | 120Hz |
| tipe lamp | 12 pcsCCFLEmbedded (Balance board) |
| sein koppelvlak | LVDS (4 ch, 10-bit), 82 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
