| Onderdeel nommer | TV101QUM-N00 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | PAD |
| Resolusie | 3840×2160 |
| Samestelling | LCM |
| Helderheid | 450 |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel model | TV101QUM-N00 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 10.1 inch |
| resolusie | 3840(RGB)×2160 , UHD |
| vertoonmodus | ADS, Normally Black, Transmissive |
| aktiewe area | 222.912×125.388 mm |
| buitelyn | 231.6×140.9 mm |
| oppervlak | |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 1500:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE1931100% |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 8S6PWLEDWithout Driver |
| sein koppelvlak | eDP (4 Lanes), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | PAD |
