| Onderdeel nommer | STCG057QVLAM-G02-S |
| Handelsmerk | Kyocera |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| handelsmerk | Kyocera |
| model | STCG057QVLAM-G02-S |
| diagonale grootte | 5.7 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 320(RGB)×240 [QVGA] 70PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 115.2(H)×86.4(V) mm |
| buitelyn dof. | 144(H)×104.8(V) ×13.5(D) mm |
| ring area | 118.4(H)×89.0(V) mm |
| behandeling | Glare (Haze 0%) |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 10/25 (Typ.)(Tr/Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥5) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K 60% NTSC |
| Ligbron | WLED , 40K hours , W/O Driver |
| gewig | 158g (Typ.) |
| ontwerp vir | Industrial |
| raamkoers | - |
| raakpaneel | Without |
| koppelvlak tipe | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
