| Onderdeel nommer | KG057QV1CA-G020 |
| Handelsmerk | Kyocera |
| Grootte | 5.7 |
| Toepassing | IA |
| Resolusie | 320×240 |
| Samestelling | LCM |
| Helderheid | 260 |
| CR | 4:1 |
| Kleure | Monochrome |
| Agterlig | CCFL |
| Koppelvlak | Parallel Data |
| paneel handelsmerk | Kyocera |
| paneel model | KG057QV1CA-G020 |
| paneel tipe | STN-LCD , LCM |
| paneel grootte | 5.7 inch |
| resolusie | 320×240 , QVGA |
| vertoonmodus | STN, Blue mode (Negative), Transmissive |
| aktiewe area | 115.18×86.38 mm |
| buitelyn | 144×104.8×13.2 mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 260 cd/m² (Typ.) |
| kontras verhouding | 4:1 (Typ.) |
| kleure vertoon | Monochrome |
| reaksie tyd | 380/120 (Typ.)(Tr/Td) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekwensie | 75Hz |
| tipe lamp | 1 pcsCCFLOptional |
| sein koppelvlak | Parallel Data (4-bit), 20 pins |
| insetspanning | 3.3/5.0V (Typ.)(VDD) |
| aansoek | IA |
