| Onderdeel nommer | MC57T04L |
| Handelsmerk | Other |
| Grootte | 5.7 |
| Toepassing | IA |
| Resolusie | 320×240 |
| Samestelling | LCM |
| Helderheid | 120 |
| CR | 30:1 |
| Kleure | Color |
| Agterlig | CCFL |
| Koppelvlak | Parallel Data |
| paneel handelsmerk | Arima |
| paneel model | MC57T04L |
| paneel tipe | CSTN-LCD , LCM |
| paneel grootte | 5.7 inch |
| resolusie | 320(RGB)×240 , QVGA |
| vertoonmodus | STN, Normally Black, Transmissive |
| aktiewe area | 115.2×86.4 mm |
| buitelyn | 154.6×114.8×10.5 mm |
| oppervlak | Antiglare |
| helderheid | 120 cd/m² (Typ.) |
| kontras verhouding | 30:1 (Min.) |
| kleure vertoon | Color |
| reaksie tyd | 250/200 (Typ.)(Tr/Td) |
| kykhoek | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| tipe lamp | 1 pcsCCFLWithout Driver |
| sein koppelvlak | Parallel Data (8-bit), 15 pins |
| insetspanning | 3.3V (Typ.) |
| rohs: | |
| aansoek | IA |
