| Onderdeel nommer | HGS128641-Y-EH-LV |
| Handelsmerk | Other |
| Grootte | 2.7 |
| Toepassing | IA |
| Resolusie | 128×64 |
| Samestelling | OLED |
| Helderheid | |
| CR | |
| Kleure | Mono(Yellow) |
| Agterlig | self |
| Koppelvlak | CPU/SPI/I²C |
| paneel handelsmerk | TSINGTEK |
| paneel model | HGS128641-Y-EH-LV |
| paneel tipe | PM-OLED , OLED |
| paneel grootte | 2.7 inch |
| resolusie | 128×64 |
| aktiewe area | 61.41×30.69 mm |
| buitelyn | 85×58×8 mm |
| oppervlak | |
| helderheid | |
| kontras verhouding | |
| kleure vertoon | Mono(Yellow) |
| kykhoek | 80/80/80/80 (Min.)(L/R/U/D) |
| sein koppelvlak | 8-bit 6800/8080 parallel, SPI, I²C, 20 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | IA |
| A027DN01 VB | AUO | 2.7 | 320×240 |
| A027DN03 V3 | AUO | 2.7 | 320×240 |
| A027DN03 V4 | AUO | 2.7 | 320×240 |
| A027DN03 V8 | AUO | 2.7 | 320×240 |
| AG-12864CYIQY-14H-A(R) | AMPIRE | 2.7 | 128×64 |
| HGS128641-Y-EH-LV | Other | 2.7 | 128×64 |
| HGS128645-Y-EH-LV | Other | 2.7 | 128×64 |
| HGS128647-Y-EH-LV | Other | 1.54 | 128×64 |
| LS027B7DH01 | SHARP | 2.7 | 400×240 |
| OEL9M5003-Y-E | Other | 2.7 | 128×64 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| DLC0560AIG-3 | Other | 5.6 | 640×480 |
| G150XG03 V2 | AUO | 15.0 | 1024×768 |
| G185BGE-L01 | Innolux | 18.5 | 1366×768 |
| LQ10D367 | SHARP | 10.4 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
| NL8060AC26-11 | NLT | 10.4 | 800×600 |
| PD057VU7 | E Ink | 5.7 | 320×240 |
| PD104SLG | E Ink | 10.4 | 800×600 |
| PD104VT1 | E Ink | 10.4 | 640×480 |
