| Onderdeel nommer | BT140GW01 V.0 |
| Handelsmerk | Innolux |
| Grootte | 14.0 |
| Toepassing | NBPC |
| Resolusie | 1366×768 |
| Samestelling | LCM |
| Helderheid | 220 |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | INNOLUX |
| paneel model | BT140GW01 V.0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 14.0 inch |
| resolusie | 1366(RGB)×768 , WXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 309.399×173.952 mm |
| buitelyn | 323.5×192×5.2 mm |
| vorm styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| oppervlak | Glare (Haze 0%), Hard coating (3H) |
| helderheid | 220 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193160% |
| reaksie tyd | 8 (Typ.)(Tr+Td) |
| kykhoek | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (1 ch, 6-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.4 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.5 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.A | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.2 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.9 | Innolux | 14.0 | 1366×768 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| LTN140KT03 | Samsung | 14.0 | 1600×900 |
| N140BGE-L23 | Innolux | 14.0 | 1366×768 |
| B101EW01 V1 | AUO | 10.1 | 1280×720 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| LP125WH2-TLFA | LG Display | 12.5 | 1366×768 |
| LP156WF4-SPC1 | LG Display | 15.6 | 1920×1080 |
| LTN121XJ-L05 | Samsung | 12.1 | 1024×768 |
| LTN133AT17-104 | Samsung | 13.3 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M140NWR2 R0 | IVO | 14.0 | 1366×768 |
| N133BGE-L21 | Innolux | 13.3 | 1366×768 |
| N141C1-L01 | Innolux | 14.1 | 1440×900 |
