| Onderdeel nommer | B140QAN02.2 |
| Handelsmerk | AUO |
| Grootte | 14.0 |
| Toepassing | Laptop |
| Resolusie | 2560×1440 |
| Samestelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | AUO |
| paneel model | B140QAN02.2 |
| paneel grootte | 14.0" |
| paneel tipe | LTPS TFT-LCD, LCM |
| resolusie | 2560(RGB)×1440, Quad-HD, 210PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 309.35(W)×174.01(H) mm |
| ring opening | - |
| omtrek grootte | 315.05(W)×195.6(H) ×2.4(D) mm |
| oppervlak | Hard coating (3H) |
| helderheid | - |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M |
| tipe lamp | WLED , 15K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| aansoek | Laptop |
| sein koppelvlak | eDP (4 Lanes) Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
