| Onderdeel nommer | B140QAN01.0 |
| Handelsmerk | AUO |
| Grootte | 14.0 |
| Toepassing | NBPC |
| Resolusie | 2560×1440 |
| Samestelling | LCM |
| Helderheid | 340 |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | AUO |
| paneel model | B140QAN01.0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 14.0 inch |
| resolusie | 2560(RGB)×1440 , Quad-HD |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| aktiewe area | 309.35×174.01 mm |
| buitelyn | 320.4×205.1×2.6 mm |
| vorm styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| oppervlak | Hard coating (3H) |
| helderheid | 340 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193172% |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | eDP (4 Lanes), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
