| Onderdeel nommer | WEO012864QS |
| Handelsmerk | Winstar |
| Grootte | 2.7 |
| Toepassing | Home Appliance Handh |
| Resolusie | 128×64 |
| Samestelling | PM-OLED, OLED |
| Helderheid | |
| CR | |
| Kleure | Mono(Blue) |
| Agterlig | self |
| Koppelvlak | |
| handelsmerk | Winstar |
| model | WEO012864QS |
| diagonale grootte | 2.7 inch |
| tipe | PM-OLED, OLED |
| pixel formaat | 128×64 52PPI |
| konfigurasie | Rectangle |
| aktiewe area | 61.41(H)×30.69(V) mm |
| buitelyn dof. | 73(H)×41.86(V) ×2.15(D) mm |
| ring area | 63.41(H)×32.69(V) mm |
| behandeling | - |
| kyk rigting | Symmetry |
| reaksie tyd | - |
| kykhoek | - |
| bedryfsmodus | - |
| ondersteun kleur | Mono(Blue) |
| Ligbron | self |
| gewig | - |
| ontwerp vir | Home Appliance Handheld & PDA Healthcare Instruments & Meters |
| raamkoers | - |
| raakpaneel | Without |
| Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
