| Onderdeel nommer | A027DN03 V1 |
| Handelsmerk | AUO |
| Grootte | 2.7 |
| Toepassing | DSC |
| Resolusie | 320×240 |
| Samestelling | LCM |
| Helderheid | 350 |
| CR | 300:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | Serial RGB |
| paneel handelsmerk | AUO |
| paneel model | A027DN03 V1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 2.7 inch |
| resolusie | 320(RGB)×240 , QVGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 54×40.5 mm |
| buitelyn | 63.5×46.6×2.4 mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 300:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit) |
| reaksie tyd | 10/25 (Typ.)(Tr/Td) |
| kykhoek | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 2S1PWLEDWithout Driver |
| sein koppelvlak | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| insetspanning | 3.3/13/-10V (VDD/VGH/VGL) |
| aansoek | DSC |
