| Onderdeel nommer | WEO012864GG |
| Handelsmerk | Winstar |
| Grootte | 2.4 |
| Toepassing | Handheld & PDA I |
| Resolusie | 128×64 |
| Samestelling | PM-OLED, OLED |
| Helderheid | |
| CR | |
| Kleure | Mono(Green) |
| Agterlig | self |
| Koppelvlak | 8-bit |
| handelsmerk | Winstar |
| model | WEO012864GG |
| diagonale grootte | 2.4 inch |
| tipe | PM-OLED, OLED |
| pixel formaat | 128×64 59PPI |
| konfigurasie | Rectangle |
| aktiewe area | 55.01(H)×27.49(V) mm |
| buitelyn dof. | 60.5(H)×37(V) ×2.15(D) mm |
| ring area | 57.01(H)×28.9(V) mm |
| behandeling | - |
| kyk rigting | Symmetry |
| reaksie tyd | - |
| kykhoek | - |
| bedryfsmodus | - |
| ondersteun kleur | Mono(Green) |
| Ligbron | self |
| gewig | - |
| ontwerp vir | Handheld & PDA Instruments & Meters |
| raamkoers | - |
| raakpaneel | Without |
| d-ic detail | COG Built-in SSD1309ZC |
| koppelvlak tipe | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| kragtoevoer | 3.0V (Typ.) |
