| Onderdeel nommer | WEG010008AL |
| Handelsmerk | Winstar |
| Grootte | 2.4 |
| Toepassing | Instruments & Me |
| Resolusie | 100×8 |
| Samestelling | OLED, PM-OLED |
| Helderheid | |
| CR | |
| Kleure | Mono(Yellow) |
| Agterlig | self |
| Koppelvlak | CPU/SPI |
| vervaardiger | Winstar |
| model naam | WEG010008AL |
| skerm grootte | 2.4 inch |
| tipe skerm | OLED, PM-OLED |
| pixel nommer | 100×8 42PPI |
| reëling | Rectangle |
| aktiewe area (mm) | 59.95 × 6.35 (H×V) |
| buitelyn (mm) | 80 × 36 × 10 (H×V×D) |
| ring area (mm) | 66.0 × 16.0 (H×V) |
| behandeling | - |
| kykhoek | - |
| reaksie | - |
| goeie uitsig by | Symmetry |
| werksmodus | - |
| kleurdiepte | Mono(Yellow) |
| agterlig | self |
| massa | - |
| gebruik vir | Instruments & Meters |
| herlaaitempo | - |
| raakskerm | Without |
| bestuurder ic lys | Built-in COB WS0010 |
| sein tipe | CPU/SPI , Pad 16 pins |
| spanningstoevoer | 5.0V (Typ.) |
