| Onderdeel nommer | TX38D18VM2BAA |
| Handelsmerk | HITACHI |
| Grootte | 15.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1024×768 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K/16.7M |
| Agterlig | 13S3P |
| Koppelvlak | |
| vervaardiger | HITACHI |
| model naam | TX38D18VM2BAA |
| skerm grootte | 15.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×768 (XGA) 85PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 304.128 × 228.096 (H×V) |
| buitelyn (mm) | 326.5 × 253.5 × 12.03 (H×V×D) |
| ring area (mm) | 307.4 × 231.3 (H×V) |
| behandeling | Antiglare |
| helderheid | 1100 cd/m² (Typ.) |
| kontras verhouding | 700 : 1 (Typ.) (TM) |
| kykhoek | 80/80/70/70 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | 12 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 262K/16.7M 59% NTSC |
| agterlig | 13S3P WLED , 50K hours , With LED Driver |
| massa | 1.10Kgs (Typ.) |
| gebruik vir | Industrial Outdoor High Brightness |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 70 °C |
| AC150XA03 | Mitsubishi | 15.0 | 1024×768 |
| HV150UX1-100 | HYDIS | 15.0 | 1600×1200 |
| LK150V3GZ13Z | SHARP | 15.0 | 640×480 |
| LM150X08-A4K3 | LG Display | 15.0 | 1024×768 |
| LQ150X1LGN2 | SHARP | 15.0 | 1024×768 |
| LQ150X1LW73 | SHARP | 15.0 | 1024×768 |
| LTM15C423S | TOSHIBA | 15.0 | 1024×768 |
| TX38D12VC0CAA | KOE | 15.0 | 1024×768 |
| TX38D14VC0CAA | KOE | 15.0 | 1024×768 |
| TX38D18VM2BAA REV.B | KOE | 15.0 | 1024×768 |
