| Onderdeel nommer | TX18D210VM0BAA |
| Handelsmerk | KOE |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 800×480 |
| Samestelling | LCM , LTPS TFT-LCD |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| vervaardiger | KOE |
| skerm grootte | 7.0 inch |
| pixel nommer | 800(RGB)×480 (WVGA) 133PPI |
| aktiewe area (mm) | 152.4 × 91.44 (H×V) |
| ring area (mm) | 156.2 × 94.5 (H×V) |
| helderheid | 800 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 262K 72% NTSC |
| massa | 214g (Typ.) |
| herlaaitempo | 60Hz |
| sein tipe | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| model naam | TX18D210VM0BAA |
| tipe skerm | LCM , LTPS TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| behandeling | - |
| kontras verhouding | 1200 : 1 (Typ.) (TM) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| werksmodus | IPS, Normally Black, Transmissive |
| agterlig | WLED , 50K hours , With LED Driver |
| gebruik vir | Industrial Outdoor High Brightness Automotive Display |
| raakskerm | Without |
