| Onderdeel nommer | TV101WXM-AG0 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 800×1280 |
| Samestelling | Assembly , a-Si TF |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 6S6P |
| Koppelvlak | MIPI |
| vervaardiger | BOE |
| model naam | TV101WXM-AG0 |
| skerm grootte | 10.1 inch |
| tipe skerm | Assembly , a-Si TFT-LCD |
| pixel nommer | 800(RGB)×1280 (WXGA) 150PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 135.322 × 216.463 (H×V) |
| buitelyn (mm) | 164 × 245.2 (H×V×D) |
| ring area (mm) | - |
| behandeling | Anti Fingerprint, Hard coating (7H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | - |
| kleurdiepte | 16.7M 57% NTSC |
| agterlig | 6S6P WLED , 15K hours , No Driver |
| massa | 300g (Max.) |
| gebruik vir | Pad & Tablet |
| herlaaitempo | 60Hz |
| raakskerm | PCAP |
| sein tipe | MIPI (4 data lanes) , 51 pins Connector |
| spanningstoevoer | 3.3/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
