| Onderdeel nommer | EJ101IA-01C |
| Handelsmerk | Innolux |
| Grootte | 10.1 |
| Toepassing | PAD |
| Resolusie | 1280×800 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | CHIMEI INNOLUX |
| paneel model | EJ101IA-01C |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 10.1 inch |
| resolusie | 1280(RGB)×800 , WXGA |
| vertoonmodus | IPS, Normally Black, Transmissive |
| aktiewe area | 216.96×135.6 mm |
| buitelyn | 228.96×148.5×4.6 mm |
| oppervlak | Hard coating, Antireflection |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193150% |
| reaksie tyd | 10/15 (Typ.)(Tr/Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 6S6PWLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (1 ch, 8-bit), 45 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | PAD |
