| Onderdeel nommer | TPF0702002N |
| Handelsmerk | JDI |
| Grootte | 7.0 |
| Toepassing | PAD |
| Resolusie | 1200×1920 |
| Samestelling | CELL |
| Helderheid | 0 |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | No B/L |
| Koppelvlak | MIPI |
| paneel handelsmerk | JDI |
| paneel model | TPF0702002N |
| paneel tipe | LTPS TFT-LCD , CELL |
| paneel grootte | 7.0 inch |
| resolusie | 1200(RGB)×1920 , WUXGA |
| vertoonmodus | Normally Black, Transmissive |
| aktiewe area | 94.5×151.2 mm |
| buitelyn | 97.3×159.4×0.77 mm |
| oppervlak | Hard coating |
| glas diepte | 0.25+0.25 mm |
| deurlaatbaarheid | 3.8% (Typ.)(with Polarizer) |
| kontras verhouding | 1200:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193172% |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| sein koppelvlak | MIPI, 40 pins |
| insetspanning | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| aansoek | PAD |
| 70WVW3A | SII | 7.0 | 800×480 |
| BA070WS1-401 | BOE | 7.0 | 1024×600 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA070LFA1 CW | CPT | 7.0 | 800×480 |
| CLAA070NQ01 XN | CPT | 7.0 | 1024×600 |
| LD070WS2-SL02 | LG Display | 7.0 | 1024×600 |
| LT070CB01000 | TOSHIBA | 7.0 | |
| LTA070B511F | TOSHIBA | 7.0 | 800×480 |
| TPF0702001N | JDI | 7.0 | 1200×1920 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
| BP070WX1-300 | BOE | 7.0 | 800×1280 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HT121WX2-210 | HYDIS | 12.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| P080KDZ-3Z1 | Innolux | 8.0 | 1200×1920 |
| VVX07H005A90 | Panasonic | 7.0 | 800×1280 |
| YX101UWX002C | SEBO | 10.1 | 1280×800 |
