| Onderdeel nommer | HT121WX2-210 |
| Handelsmerk | HYDIS |
| Grootte | 12.1 |
| Toepassing | PAD |
| Resolusie | 1280×800 |
| Samestelling | LCM |
| Helderheid | 200 |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | HYDIS |
| paneel model | HT121WX2-210 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 12.1 inch |
| resolusie | 1280(RGB)×800 , WXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 261.12×163.2 mm |
| buitelyn | 276.8×180×6.8 mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 200 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Typ.) |
| kleure vertoon | 262K (6-bit) |
| reaksie tyd | 10/15 (Typ.)(Tr/Td) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 12S4PWLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (1 ch, 6-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | PAD |
| AA121SL01 | Mitsubishi | 12.1 | 800×600 |
| HT121WX2-210 | HYDIS | 12.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| HV121WX4-110 | HYDIS | 12.1 | 1280×800 |
| LM12S389 | SHARP | 12.1 | 800×600 |
| LQ12X12 | SHARP | 12.1 | 1024×768 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EWRF | TOSHIBA | 12.1 | 1280×800 |
| LTM12C285 | TOSHIBA | 12.1 | 800×600 |
| NL8060BC31-13A | NLT | 12.1 | 800×600 |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| HV121P01-101 | HYDIS | 12.1 | 1400×1050 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| LC104S1-A1 | LG Display | 10.4 | 800×600 |
| LQ101R1SX03 | SHARP | 10.1 | 2560×1600 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
