| Onderdeel nommer | TM097TDH01-00 |
| Handelsmerk | AVIC |
| Grootte | 9.7 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | AVIC |
| diagonale grootte | 9.7 inch |
| pixel formaat | 1024(RGB)×768 [XGA] 132PPI |
| aktiewe area | 196.608(H)×147.456(V) mm |
| ring area | 200.91(H)×152.26(V) mm |
| helderheid | 220 cd/m² (Typ.) |
| kyk rigting | 3 o'clock |
| kykhoek | 70/60/70/70 (Typ.)(CR≥10) |
| ondersteun kleur | 262K/16.7M 50% NTSC |
| gewig | 256g |
| raamkoers | 60Hz |
| model | TM097TDH01-00 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 210.2(H)×166.2(V) ×3.96(D) mm |
| behandeling | Antiglare, Hard coating (3H) |
| kontras verhouding | 500:1 (Typ.) (TM) |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED [6S6P] , 15K hours , W/O Driver |
| ontwerp vir | Industrial |
| raakpaneel | Without |
| BF097XN | Innolux | 9.7 | 1024×768 |
| ED097OC1 | E Ink | 9.7 | 1200×825 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQA | LG Display | 9.7 | 1024×768 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LTL097QL01-W01 | Samsung | 9.7 | 2048×1536 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
