| Onderdeel nommer | TM084SDHG04 |
| Handelsmerk | TIANMA |
| Grootte | 8.4 |
| Toepassing | Industrial |
| Resolusie | 800×600 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 8S3P |
| Koppelvlak | LVDS |
| paneel handelsmerk | TIANMA |
| paneel model | TM084SDHG04 |
| paneel grootte | 8.4" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 800(RGB)×600, SVGA, 119PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 170.4(W)×127.8(H) mm |
| ring opening | 173.0(W)×130.6(H) mm |
| omtrek grootte | 203(W)×143.5(H) ×7.05(D) mm |
| oppervlak | Antiglare |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 500:1 (Typ.) (TM) |
| kykhoek | 70/70/60/70 (Typ.)(CR≥10) |
| vertoonmodus | TN, Normally White, Transmissive |
| beste uitsig op | 12 o'clock |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| kleure vertoon | 262K 40% NTSC |
| tipe lamp | 8S3P WLED , 30K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 240g (Typ.) |
| aansoek | Industrial |
| sein koppelvlak | LVDS (1 ch, 6-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
