| Onderdeel nommer | TL079QDXP01 |
| Handelsmerk | TIANMA |
| Grootte | 7.9 |
| Toepassing | Pad & Tablet |
| Resolusie | 1536×2048 |
| Samestelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| handelsmerk | TIANMA |
| model | TL079QDXP01 |
| diagonale grootte | 7.9 inch |
| tipe | LTPS TFT-LCD, LCM |
| pixel formaat | 1536(RGB)×2048 325PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 119.808(H)×159.744(V) mm |
| buitelyn dof. | - |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| bedryfsmodus | SFT, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 70% NTSC |
| Ligbron | WLED |
| gewig | - |
| ontwerp vir | Pad & Tablet |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | MIPI (2 ch, 4 data lanes) Connector |
| omgewing | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| B079XAN02.0 CELL | AUO | 7.9 | 768×1024 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| B080XAN03.0 | AUO | 7.9 | 768×1024 |
| LJ640U21 | SHARP | 7.9 | 640×200 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LP079X01-SMA1 | LG Display | 7.9 | 768×1024 |
| LQ079L1SX01 | SHARP | 7.9 | 1536×2048 |
| LQ079L1SX02 | SHARP | 7.9 | 1536×2048 |
| PA079DS4 | E Ink | 7.9 | 480×234 |
| PA080XS2 | E Ink | 7.9 | 480×468 |
