| Onderdeel nommer | B080XAN02.0 |
| Handelsmerk | AUO |
| Grootte | 7.9 |
| Toepassing | PAD |
| Resolusie | 768×1024 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| paneel handelsmerk | AUO |
| paneel model | B080XAN02.0 1 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 7.9 inch |
| resolusie | 768(RGB)×1024 , XGA |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| aktiewe area | 119.808×159.744 mm |
| buitelyn | 130.7×173.19×4.35 mm |
| oppervlak | Hard coating |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193150% |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 4S5PWLEDWithout Driver |
| sein koppelvlak | MIPI (4 data lanes), 35 pins |
| insetspanning | 3.7V (Typ.) |
| aansoek | PAD |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| BP070WX6-400 | BOE | 7.0 | 800×1280 |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| Q101IRE-LA1 | Innolux | 10.1 | 1280×800 |
| TV097X0M-NS0 | BOE | 9.7 | 768×1024 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| VVF07H119A90 | Panasonic | 7.0 | 800×1280 |
