| Onderdeel nommer | TD035STEB1 |
| Handelsmerk | TPO |
| Grootte | 3.5 |
| Toepassing | MPH |
| Resolusie | 240×320 |
| Samestelling | LCM |
| Helderheid | 100 |
| CR | 80:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | Toppoly |
| paneel model | TD035STEB1 |
| paneel tipe | LTPS TFT-LCD , LCM |
| paneel grootte | 3.5 inch |
| resolusie | 240(RGB)×320 , QVGA |
| vertoonmodus | TN, Normally White, Transflective |
| aktiewe area | 53.64×71.52 mm |
| buitelyn | 64×85×4.9 mm |
| oppervlak | |
| helderheid | 100 cd/m² (Typ.) |
| kontras verhouding | 80:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| kleure vertoon | 262K (6-bit), CIE193139% |
| reaksie tyd | 10/15 (Typ.)(Tr/Td) |
| kykhoek | 45/60/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| tipe lamp | 3S2PWLEDWithout Driver |
| sein koppelvlak | Parallel RGB (1 ch, 6-bit), 50 pins |
| insetspanning | 3.3/4.5/11.1/-7V (Typ.)(VCC3/VCC5/VDD/VEE) |
| aansoek | MPH |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| CLAN050LH21 1XB | CPT | 5.0 | 540×960 |
| H546TAN01.0 | AUO | 5.5 | 720×1280 |
| LS030Q7DH01 | SHARP | 3.0 | 240×320 |
| LS032B7LX02 | SHARP | 3.2 | 320×480 |
| LS040T8LX02 | SHARP | 4.0 | 480×854 |
| OEL9M0039-R-E | Other | 1.5 | 128×128 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TM020GDH42 | Tianma | 2.0 | 176×220 |
| TM035PDZ15 | Tianma | 3.5 | 320×480 |
