| Onderdeel nommer | LS030Q7DH01 |
| Handelsmerk | SHARP |
| Grootte | 3.0 |
| Toepassing | MPH |
| Resolusie | 240×320 |
| Samestelling | LCM |
| Helderheid | 100 |
| CR | 70:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | SHARP |
| paneel model | LS030Q7DH01 |
| paneel tipe | CG-Silicon , LCM |
| paneel grootte | 3.0 inch |
| resolusie | 240(RGB)×320 , QVGA |
| vertoonmodus | TN, Normally White, Transflective |
| aktiewe area | 45.72×60.96 mm |
| buitelyn | 54.5×75 mm |
| oppervlak | Hard coating (3H) |
| helderheid | 100 cd/m² (Typ.) |
| kontras verhouding | 70:1 (Typ.)(Transmissive)2.5:1 (Typ.)(Reflective) |
| kleure vertoon | 262K (6-bit), CIE193165% |
| reaksie tyd | 30/50 (Typ.)(Tr/Td) |
| kykhoek | 40/40/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| tipe lamp | 5S1PWLEDWithout Driver |
| sein koppelvlak | Parallel RGB (1 ch, 6-bit), 51 pins |
| insetspanning | 3.3/5.0/8.0/-4.0/-8.0V (Typ.)(VSHD/VSHA/VDD/VSSD/GVSS) |
| aansoek | MPH |
