| Onderdeel nommer | TCG121XGLPBPNN-AN40-S |
| Handelsmerk | Kyocera |
| Grootte | 12.1 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 600:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | Kyocera |
| paneel model | TCG121XGLPBPNN-AN40-S |
| paneel grootte | 12.1" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1024(RGB)×768, XGA, 105PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 245.76(W)×184.32(H) mm |
| ring opening | 249.0(W)×187.5(H) mm |
| omtrek grootte | 260.5(W)×203(H) ×10.9(D) mm |
| oppervlak | Antiglare |
| helderheid | 780 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | AWV, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 18/12 (Typ.)(Tr/Td) |
| kleure vertoon | 262K/16.2M 51% NTSC |
| tipe lamp | WLED , 50K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 555g |
| aansoek | Industrial Outdoor High Brightness |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
