| Onderdeel nommer | TCG070WVLQGPNN-AN40 |
| Handelsmerk | Kyocera |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 800×480 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 750:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | Kyocera |
| skerm grootte | 7.0 inch |
| pixel nommer | 800(RGB)×480 (WVGA) 133PPI |
| aktiewe area (mm) | 152.4 × 91.44 (H×V) |
| ring area (mm) | 154.4 × 93.4 (H×V) |
| helderheid | 1000 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 262K/16.2M 50% NTSC |
| massa | 230g |
| herlaaitempo | 60Hz |
| sein tipe | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| model naam | TCG070WVLQGPNN-AN40 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 169.8 × 109.7 × 9.7 (H×V×D) |
| behandeling | Antiglare |
| kontras verhouding | 750 : 1 (Typ.) (TM) |
| reaksie | 18/12 (Typ.)(Tr/Td) ms |
| werksmodus | AWV, Normally Black, Transmissive |
| agterlig | WLED , 70K hours , With LED Driver |
| gebruik vir | Industrial Outdoor High Brightness Automotive Display |
| raakskerm | Without |
