{{handelsmerk}} T260XW02 VB datablad, spesifikasie, aandele, toepassing www.looklcd-za.com
LookLCD LookLCD


T260XW02 VB

T260XW02 VB
T260XW02 VB
T260XW02 VB thumb T260XW02 VB thumb
Handelsmerk
AUO
Grootte
26.0
Toepassing
LCTV
Resolusie
1366×768
Samestelling
LCM
Helderheid
500
CR
800:1
Kleure
16.7M
Agterlig
CCFL
Koppelvlak
LVDS
In Stock
81
Spesifikasies

Onderdeel nommer T260XW02 VB
HandelsmerkAUO
Grootte26.0
ToepassingLCTV
Resolusie1366×768
SamestellingLCM
Helderheid500
CR800:1
Kleure16.7M
AgterligCCFL
KoppelvlakLVDS
paneel handelsmerkAUO
paneel modelT260XW02 VB 0 Compatible model
paneel tipe a-Si TFT-LCD , LCM
paneel grootte26.0 inch
resolusie1366(RGB)×768 , WXGA
vertoonmodusVA, Normally Black, Transmissive
aktiewe area575.769×323.712 mm
buitelyn626×373 mm
oppervlakAntiglare (Haze 13%), Hard coating (3H)
helderheid500 cd/m² (Typ.)
kontras verhouding800:1 (Typ.)
kleure vertoon16.7M (8-bit), CIE193172%
reaksie tyd21/4 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
kykhoek85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frekwensie60Hz
tipe lamp14 pcsCCFLEmbedded (Inverter)
sein koppelvlakLVDS (1 ch, 8-bit), 30 pins
insetspanning12.0V (Typ.)
aansoekLCTV
Familie Model
T260XVN01.1 AUO 26.0 1366×768
T260XVN01.4 AUO 26.0 1366×768
T260XW01 V3 AUO 26.0 1280×768
T260XW02 V0 AUO 26.0 1366×768
T260XW02 V9 AUO 26.0 1366×768
T260XW03 V2 AUO 26.0 1366×768
T260XW04 V5 AUO 26.0 1366×768
T260XW04 V7 AUO 26.0 1366×768
T260XW04 V8 AUO 26.0 1366×768
T260XW06 V5 AUO 26.0 1366×768
