| Onderdeel nommer | T200XW01 V0 |
| Handelsmerk | AUO |
| Grootte | 20.0 |
| Toepassing | LCTV |
| Resolusie | 1366×768 |
| Samestelling | LCM |
| Helderheid | 450 |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | T200XW01 V0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 20.0 inch |
| resolusie | 1366(RGB)×768 , WXGA |
| vertoonmodus | AMVA, Normally Black, Transmissive |
| aktiewe area | 443.609×249.408 mm |
| buitelyn | 479×278.4 mm |
| oppervlak | Hard coating (3H) |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit) |
| reaksie tyd | 15/10 (Typ.)(Tr/Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 6 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (1 ch, 8-bit), 30 pins |
| insetspanning | 5.0V (Typ.) |
| aansoek | LCTV |
| LM200WD3-TLC9 | LG Display | 20.0 | 1600×900 |
| LTM200KT03 | Samsung | 20.0 | 1600×900 |
| LTM200KT08-V | Samsung | 20.0 | 1600×900 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| LTM200KT12 | Samsung | 20.0 | 1600×900 |
| M200RW01 V3 | AUO | 20.0 | 1600×900 |
| MT200LW02 V.0 | Innolux | 20.0 | 1600×900 |
| T200XW01 V0 | AUO | 20.0 | 1366×768 |
| T200XW02 V0 | AUO | 20.0 | 1366×768 |
| T200XW02 V1 | AUO | 20.0 | 1366×768 |
| LC320DXN-SEU1 | LG Display | 31.5 | 1366×768 |
| LC320EXJ-SEK1 | LG Display | 31.5 | 1366×768 |
| LC370WX5-SLA1 | LG Display | 37 | 1366×768 |
| LC420EUN-SDV1 | LG Display | 42 | 1920×1080 |
| LC550EUN-FFM1 | LG Display | 55 | 1920×1080 |
| LTA230A172F | TOSHIBA | 23.0 | 1280×768 |
| T315HW04 V8 | AUO | 31.5 | 1920×1080 |
| T315XW01 V5 | AUO | 31.5 | 1366×768 |
| T650HVF03.0 | AUO | 65 | 1920×1080 |
| T650HVN04.1 | AUO | 65 | 1920×1080 |
