| Onderdeel nommer | S043QWQ55HG |
| Handelsmerk | CDTECH |
| Grootte | 4.3 |
| Toepassing | Automotive Display I |
| Resolusie | 480×272 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | 8S2P |
| Koppelvlak | |
| vervaardiger | CDTECH |
| skerm grootte | 4.3 inch |
| pixel nommer | 480(RGB)×272 (WQVGA) 128PPI |
| aktiewe area (mm) | 95.04 × 53.856 (H×V) |
| ring area (mm) | 98.9 × 57.7 (H×V) |
| helderheid | 500 (Typ.)(cd/m²) |
| kykhoek | 65/65/55/65 (Typ.)(CR≥10) |
| goeie uitsig by | 12 o'clock |
| kleurdiepte | 16.7M 50% NTSC |
| massa | TBD |
| herlaaitempo | 60Hz |
| model naam | S043QWQ55HG |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 105.5 × 67.2 × 3.15 (H×V×D) |
| behandeling | - |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| werksmodus | TN, Normally White, Transmissive |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| agterlig | 8S2P WLED , 25K hours , No Driver |
| gebruik vir | Automotive Display Industrial |
| raakskerm | Without |
| 43WQW1H | SII | 4.3 | 480×272 |
| 43WQW4H | SII | 4.3 | 480×272 |
| AT043TN13 TP | Innolux | 4.3 | 480×272 |
| DLC0430LZG-8 | Other | 4.3 | 480×272 |
| LB043WQ3-TD01 | LG Display | 4.3 | 480×272 |
| LMS430HF41-004 | Samsung | 4.3 | 480×272 |
| LQ043T1DH41 | SHARP | 4.3 | 480×272 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LR430RC9001 | Innolux | 4.3 | 480×272 |
| TM043NDH02 | Tianma | 4.3 | 480×272 |
