| Onderdeel nommer | S035V04-T |
| Handelsmerk | CDTECH |
| Grootte | 3.5 |
| Toepassing | Industrial Handheld |
| Resolusie | 480×640 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 8S1P |
| Koppelvlak | Parallel |
| paneel handelsmerk | CDTECH |
| paneel model | S035V04-T |
| paneel grootte | 3.5" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 480(RGB)×640, VGA, 228PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 53.28(W)×71.04(H) mm |
| ring opening | - |
| omtrek grootte | 64(W)×85(H) ×5(D) mm |
| oppervlak | - |
| helderheid | 650 cd/m² (Typ.) |
| kontras verhouding | 500:1 (Typ.) (TM) |
| kykhoek | 65/65/55/65 (Typ.)(CR≥10) |
| vertoonmodus | TN, Normally White, Transmissive |
| beste uitsig op | 9 o'clock |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kleure vertoon | 262K 50% NTSC |
| tipe lamp | 8S1P WLED , 25K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | 4-wire Resistive Touch |
| paneel gewig | TBD |
| aansoek | Industrial Handheld & PDA |
| sein koppelvlak | Parallel RGB (1 ch, 6-bit) , 39 pins FPC |
| insetspanning | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
