| Onderdeel nommer | LH350H01-FD01-A41 |
| Handelsmerk | LG Display |
| Grootte | 3.5 |
| Toepassing | MPH |
| Resolusie | 320×480 |
| Samestelling | LCM |
| Helderheid | 450 |
| CR | 200:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| paneel handelsmerk | LG Display |
| paneel model | LH350H01-FD01-A41 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 3.5 inch |
| resolusie | 320(RGB)×480 , HVGA |
| vertoonmodus | TN, Normally White, Transflective |
| aktiewe area | 49.92×74.88 mm |
| buitelyn | 55.14×82.84×2.25 mm |
| oppervlak | |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 200:1 (Typ.)(Transmissive) |
| kleure vertoon | 16.7M (8-bit) |
| reaksie tyd | 6/20 (Typ.)(Tr/Td); 40 (Typ.)(G to G) |
| kykhoek | 60/60/60/57 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 6S1PWLEDWithout Driver |
| sein koppelvlak | MIPI (2 data lanes), 20 pins |
| insetspanning | 3.0/5.672/1.8V (Typ.)(VDDC/VDDA/LOVCC) |
| aansoek | MPH |
