| Onderdeel nommer | QD14XL20 Rev.03 |
| Handelsmerk | QDI |
| Grootte | 14.1 |
| Toepassing | NBPC |
| Resolusie | 1024×768 |
| Samestelling | LCM |
| Helderheid | 185 |
| CR | 300:1 |
| Kleure | 262K |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | QDI |
| paneel model | QD14XL20 Rev.03 1 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 14.1 inch |
| resolusie | 1024(RGB)×768 , XGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 285.696×214.272 mm |
| buitelyn | 299×240.6×5.5 mm |
| vorm styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| oppervlak | Antiglare, Hard coating (3H), Reflection 5.0% (Max.) |
| helderheid | 185 cd/m² (Typ.) |
| kontras verhouding | 300:1 (Min.) |
| kleure vertoon | 262K (6-bit), CIE193142% |
| reaksie tyd | 10/15 (Typ.)(Tr/Td) |
| kykhoek | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 1 pcsCCFLEmbedded (Inverter) |
| sein koppelvlak | LVDS (1 ch, 6-bit), 30 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
