| Onderdeel nommer | NV156FHM-A12 |
| Handelsmerk | BOE |
| Grootte | 15.6 |
| Toepassing | Laptop |
| Resolusie | 1920×1080 |
| Samestelling | Assembly , a-Si TF |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K |
| Agterlig | 8S5P |
| Koppelvlak | eDP |
| vervaardiger | BOE |
| skerm grootte | 15.6 inch |
| pixel nommer | 1920(RGB)×1080 (FHD) 141PPI |
| aktiewe area (mm) | 344.16 × 193.59 (H×V) |
| ring area (mm) | - |
| helderheid | 230 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 262K 45% NTSC |
| omtrek vorm | Slim (PCBA Flat, T≤3.2mm) |
| herlaaitempo | 60Hz |
| sein tipe | eDP (2 Lanes) , 30 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model naam | NV156FHM-A12 (BOE065E) |
| tipe skerm | Assembly , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 374.9 × 236.4 × 4.2 (H×V×D) |
| behandeling | Anti-Scatter, Hard coating (9H), Antireflection |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| werksmodus | - |
| agterlig | 8S5P WLED , 15K hours , With LED Driver |
| gebruik vir | Laptop |
| raakskerm | PCAP, Optical Bonding |
| B156XTK01.0 | AUO | 15.6 | 1366×768 |
| CLAA156WB11A | CPT | 15.6 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLE1 | LG Display | 15.6 | 1920×1080 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LP156WHB-TPD1 | LG Display | 15.6 | 1366×768 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
| SVA156WX1-01TB | SVA-NEC | 15.6 | 1366×768 |
