| Onderdeel nommer | NV156FHM-N43 |
| Handelsmerk | BOE |
| Grootte | 15.6 |
| Toepassing | NBPC |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 800:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel model | NV156FHM-N43 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 15.6 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | ADS, Normally Black, Transmissive |
| aktiewe area | 334.16×193.59 mm |
| buitelyn | 359.5×223.8×3.2 mm |
| vorm styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| oppervlak | Antiglare |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193172% |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 9S6PWLEDEmbedded (LED Driver) |
| sein koppelvlak | eDP (2 Lanes), 30 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
| BT156GW01 V.3 | Innolux | 15.6 | 1366×768 |
| LP156WH2-TLQ2 | LG Display | 15.6 | 1366×768 |
| LTN156AT01-A01 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-W01 | Samsung | 15.6 | 1366×768 |
| LTN156AT11-A01 | Samsung | 15.6 | 1366×768 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
| B154EW01 V4 | AUO | 15.4 | 1280×800 |
| CLAA140UA01 CN | CPT | 14.0 | 1600×900 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
| LTN140AT02-B01 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-W01 | Samsung | 14.0 | 1366×768 |
| LTN141AT13-B01 | Samsung | 14.1 | 1280×800 |
| LTN141W1-L09-1 | Samsung | 14.1 | 1280×800 |
| LTN150PF-L02 | Samsung | 15.0 | 1400×1050 |
| LTN170WA-L01 | Samsung | 17.0 | 1440×900 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
