| Onderdeel nommer | NV140DQM-N51 |
| Handelsmerk | BOE |
| Grootte | 14.1 |
| Toepassing | Laptop |
| Resolusie | 1920×550 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | 10S6P |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel model | NV140DQM-N51 (BOE0922) |
| paneel grootte | 14.1" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×550, 141PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 344.218(W)×98.604(H) mm |
| ring opening | - |
| omtrek grootte | 350.52(W)×118.65(H) ×2.5(D) mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | ADS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 100% sRGB |
| tipe lamp | 10S6P WLED , 15K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| aansoek | Laptop |
| sein koppelvlak | eDP (2 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 65 °C |
