| Onderdeel nommer | NT133WHM-N45 |
| Handelsmerk | BOE |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 1366×768 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 8S4P |
| Koppelvlak | eDP |
| vervaardiger | BOE |
| model naam | NT133WHM-N45 (BOE07AD) 6 Compatible |
| skerm grootte | 13.3 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1366(RGB)×768 (WXGA) 118PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 293.42 × 164.97 (H×V) |
| buitelyn (mm) | 300.26 × 187.27 × 3 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 220 cd/m² (Typ.) |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥10) |
| reaksie | 12 (Typ.)(Tr+Td) ms |
| goeie uitsig by | 6 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 262K 45% NTSC |
| agterlig | 8S4P WLED , 15K hours , With LED Driver |
| omtrek vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruik vir | Laptop |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , Connector 30 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B133XTN01.2 | AUO | 13.3 | 1366×768 |
| B133XW07 V2 | AUO | 13.3 | 1366×768 |
| LP133WH1-TLA2 | LG Display | 13.3 | 1366×768 |
| LP133WX3-TLA1 | LG Display | 13.3 | 1280×800 |
| LTN133AT03-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT05-S02 | Samsung | 13.3 | 1280×800 |
| LTN133AT07-G01 | Samsung | 13.3 | 1280×800 |
| LTN133AT23-X01 | Samsung | 13.3 | 1366×768 |
| N133BGE-EAB | Innolux | 13.3 | 1366×768 |
| N133I5-L01 | Innolux | 13.3 | 1280×800 |
