| Onderdeel nommer | NL192108BC18-06F |
| Handelsmerk | NLT |
| Grootte | 15.6 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1920×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 750:1 |
| Kleure | 16.7M |
| Agterlig | 4 |
| Koppelvlak | eDP |
| vervaardiger | NLT |
| model naam | NL192108BC18-06F |
| skerm grootte | 15.6 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 141PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 344.16 × 193.59 (H×V) |
| buitelyn (mm) | 363.8 × 215.9 × 16.2 (H×V×D) |
| ring area (mm) | 347.55 × 196.75 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 1500 cd/m² (Typ.) |
| kontras verhouding | 750 : 1 (Typ.) (TM) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| reaksie | 15/15 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | UA-SFT, Normally Black, Transmissive |
| kleurdiepte | 16.7M 40% NTSC |
| agterlig | 4 strings WLED , 50K hours , No Driver |
| massa | 1.05/1.15Kgs (Typ./Max.) |
| gebruik vir | Industrial Outdoor High Brightness |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
