| Onderdeel nommer | NL192108AC10-01D |
| Handelsmerk | NLT |
| Grootte | 9.0 |
| Toepassing | IA |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 700:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | NLT |
| paneel model | NL192108AC10-01D |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 9.0 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | UA-SFT, Normally Black, Transmissive |
| aktiewe area | 198.72×111.78 mm |
| buitelyn | 214.6×130×9.6 mm |
| oppervlak | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) |
| kleure vertoon | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| reaksie tyd | 13/12 (Typ.)(Tr/Td) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (2 ch, 6/8-bit), 50 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | IA |
| A090PAN01.0 | AUO | 9.0 | 900×1440 |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| LTA090A220F | TOSHIBA | 9.0 | 800×480 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
| NL6448BC28-01 | NLT | 9.0 | 640×480 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
| AA150XN03 | Mitsubishi | 15.0 | 1024×768 |
| DLC1010DZG-T-8 | Other | 10.1 | 1280×800 |
| G185HAN01.0 | AUO | 18.5 | 1920×1080 |
| KCB6448BSTT-X1 | Kyocera | 10.4 | 640×480 |
| LJ640U35 | SHARP | 8.9 | 640×400 |
| LM12S49 | SHARP | 12.1 | 800×600 |
| LM64C12P | SHARP | 9.4 | 640×480 |
| LM64P10 | SHARP | 7.2 | 640×480 |
| MD480L640PG4 | Panasonic | 10.4 | 640×480 |
| UG-9616TLBBG01 | WiseChip | 0.84 | 96×16 |
