| Onderdeel nommer | NL13676BC25-07F |
| Handelsmerk | NLT |
| Grootte | 15.6 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | 6 |
| Koppelvlak | LVDS |
| paneel handelsmerk | NLT |
| paneel grootte | 15.6" |
| resolusie | 1366(RGB)×768, WXGA, 100PPI |
| vertoon area | 344.232(W)×193.536(H) mm |
| omtrek grootte | 363.8(W)×215.9(H) ×13.15(D) mm |
| helderheid | 1250 cd/m² (Typ.) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K/16.7M 60% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 1.07/1.17Kgs (Typ./Max.) |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| paneel model | NL13676BC25-07F |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 347.55(W)×196.85(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 3/15 (Typ.)(Tr/Td) |
| tipe lamp | 6 strings WLED , 7K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial Outdoor High Brightness |
