| Onderdeel nommer | NE156QUM-N6A |
| Handelsmerk | BOE |
| Grootte | 15.6 |
| Toepassing | Laptop |
| Resolusie | 3840×2160 |
| Samestelling | Oxide TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | BOE |
| model | NE156QUM-N6A (BOE0809) |
| diagonale grootte | 15.6 inch |
| tipe | Oxide TFT-LCD, LCM |
| pixel formaat | 3840(RGB)×2160 [UHD] 283PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 344.218(H)×193.622(V) mm |
| buitelyn dof. | 350.66(H)×216.12(V) ×2.6(D) mm |
| ring area | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 600 cd/m² (Typ.) |
| kontras verhouding | 1400:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 100% Adobe RGB |
| Ligbron | WLED , 15K hours , With LED Driver |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| ontwerp vir | Laptop |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 70 °C |
| B156HAK01.0 | AUO | 15.6 | 1920×1080 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| LP156WD1-TLD5 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLF3 | LG Display | 15.6 | 1920×1080 |
| LP156WF3-SLB2 | LG Display | 15.6 | 1920×1080 |
| LP156WF4-SPK1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TPB1 | LG Display | 15.6 | 1366×768 |
| N156HGE-EA1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-LG1 | Innolux | 15.6 | 1920×1080 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
