| Onderdeel nommer | MV238FHM-N01 |
| Handelsmerk | BOE |
| Grootte | 23.8 |
| Toepassing | Desktop Monitor |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | BOE |
| paneel grootte | 23.8" |
| resolusie | 1920(RGB)×1080, FHD, 92PPI |
| vertoon area | 527.04(W)×296.46(H) mm |
| helderheid | 250 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 72% NTSC |
| frekwensie | 60Hz |
| paneel gewig | - |
| sein koppelvlak | LVDS (2 ch, 8-bit) , 30 pins Connector |
| insetspanning | 5.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | MV238FHM-N01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | ADS, Normally Black, Transmissive |
| reaksie tyd | 14 (Typ.)(G to G) |
| tipe lamp | WLED , 30K hours , Without Driver |
| raakskerm | Without |
| aansoek | Desktop Monitor |
